GAG-3 Electromechanical Actuator

GAG3

Got a demanding job with shiftable loads up to 2,240 lbs (1,016 kg)? Then try the rugged GAG-3 Actuator. It provides the extra thrust you need to handle even the most demanding jobs. The actuator utilizes a 2.0-Amp, 1,560 motor to deliver enough power for any application. This gear-driven actuator also features fast shifting speeds of 0.87 inch/sec (22 mm/sec), and standard actuator strokes ranging from 1â€157; to 12â€157; (25 to 305 mm) in 1â€157; (25 mm) increments.

Ball screw and nut design provides low-friction, efficient operation, and eliminates the typical end-of-stroke sticking and/or the need for actuator limit switches. For use with Fife's CDP-01 or CSP-01 Processors, this actuator is widely used for steering guides, displacement guides, positioner assemblies, slaving, chasing applications, and unwind/rewind applications.



Key Features:

  • Gear-driven actuator with shiftable loads up to 2,240 lbs (1,016 kg).
  • Clean, electronic operation.
  • Durable construction for continuous-duty reliability.
  • Non sticking end of stroke design.
  • No limit switches required.
  • Compatible with all Fife automated guiding and positioning equipment.
  • Sized and configured to your requirements.


Additional Specifications:



Maximum Shiftable Load:
2,240 lbs (1,016 kg)
(using anti friction bearings)



Maximum Design Thrust:
224 lbf (996 N)



Maximum Shifting Speed:
0.87 inch/sec (22 mm/sec)
